Ñ ÿíâàðÿ 2005 ãîäà ïîñòóïàþò â ïðîäàæó êîìïîíåíòû äëÿ äîìàøíåãî êèíîòåàòðà – íîâàÿ êîíöåïöèÿ â òåõíîëîãèè.

Product	Description	Suggested Retail
SSP100	Surround Sound Processor	US$13,770
SSP80	Surround Sound Processor	US$11,670
MCA20	2 channel power amplifier	US$6,870
MCA30	3 channel power amplifier	US$7,470
MCA50	5 channel power amplifier	US$8,370
MCA70	7 channel power amplifier	US$9,870
UNI90	Universal Format Player	-

Super Definition Multi Channel Power Amplifiers Halcro

• Power Output: 350W RMS continuous into 4 Ohms

• Distortion THD: <0.005% at 1kHz at all powers up to 350W into 4 Ohms,

<0.02% at 7kHz at all powers up to 350W (typically <0.01% at 350W)

• Unbalanced and Balanced Voltage Inputs

• Mains Voltage: 100 - 120VAC or 190 - 250VAC

• Remote trigger switch between On & Standby

• Command Functions:

- Switch between On & Standby

- Ability to inhibit individual amplifier modules

- Amplifier module will indicate Over Temperature condition

• Halcro Reliability Assurance Service

• Power Output: 350W RMS continuous into 4 Ohms

• Distortion THD: <0.005% at 1kHz at all powers up to 350W into 4 Ohms,

<0.02% at 7kHz at all powers up to 350W (typically <0.01% at 350W)

• Unbalanced and Balanced Voltage Inputs

• Mains Voltage: 100 - 120VAC or 190 - 250VAC

• Remote trigger switch between On & Standby

• Command Functions:

- Switch between On & Standby

- Ability to inhibit individual amplifier modules

- Amplifier module will indicate Over Temperature condition

• Halcro Reliability Assurance Service

• Power Output: 400W RMS continuous into 4 Ohms

• Distortion THD: <0.005% at 1kHz at all powers up to 400W into 4 Ohms

<0.02% at 7kHz at all powers up to 400W (typically <0.01% at 400W)

• Unbalanced and Balanced Voltage Inputs

• Mains Voltage: 100 - 120VAC or 190 - 250VAC

• Remote trigger switch between On & Standby

• Command Functions:

- Switch between On & Standby

- Ability to inhibit individual amplifier modules

- Amplifier module will indicate Over Temperature condition

• Halcro Reliability Assurance Service

• Power Output: 400W RMS continuous into 4 Ohms

• Distortion THD: <0.005% at 1kHz at all powers up to 400W into 4 Ohms,

<0.02% at 7kHz at all powers up to 400W (typically <0.01% at 400W)

• Unbalanced and Balanced Voltage Inputs

• Mains Voltage: 100 - 120VAC or 190 - 250VAC

• Remote trigger switch between On & Standby

• Command Functions:

- Switch between On & Standby

- Ability to inhibit individual amplifier modules

- Amplifier module will indicate Over Temperature condition

• Halcro Reliability Assurance Service

Super Definition Surround Sound Processors

Halcro Logic Surround Sound Processors are the next generation of home theater processors/

preamplifiers. A complete solution for the needs of all home theater connoisseurs, both models have significant technological advantages over other brands. HDMI connection between a DVD and a Processor means only one cable is needed to transport audio and video signals. HDMI reduces the traditional tangle of wiring with current connections and gives maximum quality Audio & Video signals because there is no compression. A full list of HDMI & DVI features & specifications is included in the back of this brochure.

Multi channel SACD & DVD Audio playback is through analogue bypass. This preserves signal integrity resulting in the highest standard of music reproduction.

USB connection enables you to control the entire system with your PC or home automation software and also allows for easy software upgrades as technology evolves.

Super Definition Sound & VisionTM is the only term that fully describes the SSP100 & SSP80.

AUDIO

• 7.1 channel balanced inputs and outputs with analogue bypass and volume control

• 7.1 channel unbalanced inputs with selectable unbalanced and balanced outputs

• 4 special, programmable output channels. Auxiliary Manager for managing additional

channels (channels 9 & 10 for stereo subwoofers, ceiling speakers, etc.)

• Play music and/or video in two different rooms

• Patented High Dynamic Bass (HDB) circuitry for advanced bass management

Choose the size of speakers & route the bass information through the subwoofer(s)

• Autocalibration of speaker levels and distances with calibration microphone

Simplifies set up for best in-room audio quality

• Adjustable Lipsync function

VIDEO

• 4 HDMI inputs. Digital audio & video can be sent from the DVD player

direct to the processor and/or projector/plasma display

• 1 HDMI output. DVI fully supported via HDMI to DVI adaptor

• HDMI de-interlacing and scaling for improved video performance

• Up-conversion (scaler) to component video & HDMI

• 4 component video inputs

• 1 component video output

• Composite and Component Video de-interlacing (interlaced to progressive

translation, e.g. 480i to 480p) + scaling to HDTV 1080p and/or HDMI output

• Component Video bypass switching (up to HDTV 1080p compatible)

Analogue video to Digital, High Definition video conversion

AUDIO

• 7.1 channel unbalanced input with analogue bypass and volume control

• 7.1 channel balanced & unbalanced multi channel outputs

• Assignable stereo balanced input with analogue bypass and volume control

• 4 special, programmable output channels

• Play music and/or video in two different rooms

• Auxiliary Manager for managing additional channels (channels 9 & 10 for stereo

subwoofers, ceiling speakers, etc.)

• Patented High Dynamic Bass (HDB) circuitry for advanced bass management

Choose the size of speakers & route the bass information through the subwoofer(s)

• Autocalibration of speaker levels and distances with calibration microphone

Simplifies set up for best in-room audio quality

VIDEO

• Adjustable Lipsync function

• 3 HDMI inputs. Digital audio & video can be sent from the DVD player

direct to the processor and/or projector/plasma display

• 1 HDMI output. DVI fully supported via HDMI to DVI adaptor

• Component Video bypass switching (up to HDTV 1080p compatible)

Analogue video to Digital, High Definition video conversion

• HDMI bypass switching; passes digital video in its native resolution to the

projector/plasma display

• 3 component video inputs, 1 output

• Composite, S-Video to component or HDMI up-conversion

• Component Video to HDMI conversion

Super Definition Universal Player

With the variety of software formats available such as CD, SACD, DVD and DVDA, it is wise to choose a universal format player which is designed not only for super definition video, but also to deliver optimum performance from the various audio formats. Practically all multi format players compromise some or all of the software formats. The UNI90 has been designed to extract the most accurate detail from audio software which means added versatility as a high performance stand alone SACD/CD/DVD/DVDA/MP3 player. Not only is every sound and nuance expressed exactly as intended, the user interface is designed with simplicity and ease of use in mind.

• Supports all major formats

- DVD Video (Dolby Surround or DTS)

- DVD Audio

- Super Audio CD

- CD

- MP3

• Front loading metal disc tray

• RS232 connection

• Video

- NTSC/PAL

VIDEO OUTPUTS

• Analogue

- Component Video

- Progressive Scan

- S-Video

- Composite Video

• Digital

- HDMI

AUDIO OUTPUTS

• Analogue

- Unbalanced: Stereo, 5.1

- Balanced: Stereo (XLR), 5.1 (XLR)

• Digital

- SPDIF: RCA, Optical (Toslink)
